V15.5.2 Patch release August 2025

mmGPS for Hiper XR
With the latest GNSS firmware version 7.1, the option to use Hiper XR with mmGPS is now available.

Satel Easy Pro 35 W radio has been added
The Satel Easy Pro 35 W radio has been added to the Radio type list.

Satel TR4+ radio channel includes channel spacing
When configuring a Satel TR4+ radio, the channel spacing has been added in the list of radio channels.

GNSS conditions settings
In Supervisor mode, GNSS conditions can be set to help you obtain a more accurate position in challenging GNSS situations.

Tilt angle value is now available in Info Panel
The tilt angle value of the GNSS receiver is now available as a text value in the Info Panel.

Support latest geoids based on new JGD2024 datums for Japan
New datums have been added to Japanese projection to support latest Japanese geoids

Added ability to reconnect during station setup
During station setup when the connection to the total station is lost, Pocket 3D can now reconnect without leaving the station setup routine.

Reordered columns in layer dialog
The columns in the layer dialog are reordered, so that the name and “Show” tick box are now visible without scrolling.

“Delete” shortcut button supports now Select from map
When using the “Delete” shortcut without having any data selected, there will be a prompt to select data from the map.

Station setup and Base setup routines support now Select from map
To select points during the station setup or base setup the user can now select them from map.

Bugfixes:

Cut/fill arrows reversed in info panel
When the “Match cut/fill with Grade Indicator colour” was unticked, the Cut/fill arrows in the info panel were reversed. This issue has been resolved.

Total Station coordinates after station setup using external link
If the Total Station was using “External link”, in some instances the station coordinates changed after a station setup on reconnection (by maximum of 1m). This issue has been resolved.

Duplicating and mangling points after import csv file
An issue from the field has been reported that when importing some csv files, points are duplicated and point descriptions are mangled. This issue has been resolved.

Base station settings not being saved using external antenna
An issue from the field has been reported that if the user starts a GPS base station with external antenna (e.g. NET-G4 with G5-A1 antenna), the base station settings are not stored after connecting to a rover and switching back to the base station. This issue has been resolved.
